| import os
import pandas as pd
from torch.utils.data import Dataset
from torch.utils.data import DataLoader
from PIL import Image
from torchvision import transforms
from sklearn.model_selection import train_test_split
import torch.nn as nn
import torch.optim as optim
import torchvision.models as models
from collections import Counter
from tqdm import tqdm
import torch
import random
import numpy as np
import hashlib
class KneeXRayDataset(Dataset):
def __init__(self, dataframe, transform=None, cache_size=2000):
self.df = dataframe
self.transform = transform
self.cache={}
self.cache_size=cache_size
def __len__(self):
return len(self.df)
def __getitem__(self, idx):
if idx in self.cache:
return self.cache[idx]
row = self.df.iloc[idx]
image = Image.open(row['img_path']).convert('RGB')
label = int(row['KL'][0])
image = self.transform(image)
result=(image, label)
if len(self.cache) < self.cache_size:
self.cache[idx] = result
return result
if __name__ == '__main__':
device = torch.device('cuda' if torch.cuda.is_available() else 'cpu')
print(f'device:{device}')
seed=42
random.seed(seed); np.random.seed(seed); torch.manual_seed(seed)
if torch.cuda.is_available():
torch.cuda.manual_seed_all(seed)
exps={'MedicalExpert-I','MedicalExpert-II'}
KL_levels={'0Normal','1Doubtful','2Mild','3Moderate','4Severe'}
img_exp_KLs=[]
for root, dirs, files in os.walk(f'.{os.sep}Digital Knee X-ray Images'):
for name in files:
if name.endswith('.png'):
path_parts=set(root.split(os.sep))
img_path=os.path.join(root, name)
img_exp_KL=(img_path,(path_parts&exps).pop(),(path_parts&KL_levels).pop())
img_exp_KLs.append(img_exp_KL)
dataset_df = pd.DataFrame(img_exp_KLs,columns=['img_path','exp','KL'])
dataset_df.sort_values(by='img_path',inplace=True)
dataset_df['filename'] = dataset_df['img_path'].str.split(os.sep).str[-1]
dataset_df_unique = dataset_df.drop_duplicates(subset=['KL','filename']).reset_index(drop=True)
data_transform_train = transforms.Compose([
transforms.Resize((224, 224)),
transforms.RandomHorizontalFlip(),
transforms.RandomRotation(15),
transforms.ColorJitter(brightness=0.2, contrast=0.2),
transforms.ToTensor(),
transforms.Normalize(mean=[0.485, 0.456, 0.406],
std=[0.229, 0.224, 0.225])
])
data_transform_val = transforms.Compose([
transforms.Resize((224, 224)),
transforms.ToTensor(),
transforms.Normalize(mean=[0.485, 0.456, 0.406],
std=[0.229, 0.224, 0.225])
])
X = dataset_df_unique
y = dataset_df_unique['KL']
X_train_val, X_test, y_train_val, y_test = train_test_split(
X, y, test_size=0.2, random_state=seed, stratify=y)
X_train, X_val, y_train, y_val = train_test_split(
X_train_val, y_train_val, test_size=0.25, random_state=seed, stratify=y_train_val)
class_counts=Counter(y_train)
all_counts=len(y_train)
class_weights={cls:all_counts/cnt for cls,cnt in class_counts.items()}
class_weights=torch.tensor(list(class_weights.values()),dtype=torch.float32).to(device)
train_dataset = KneeXRayDataset(dataframe=X_train, transform=data_transform_train)
val_dataset = KneeXRayDataset(dataframe=X_val, transform=data_transform_val)
test_dataset = KneeXRayDataset(dataframe=X_test, transform=data_transform_val)
train_loader = DataLoader(train_dataset, batch_size=64, shuffle=True,
num_workers=4,pin_memory=True,persistent_workers=True)
val_loader = DataLoader(val_dataset, batch_size=64, shuffle=False,
num_workers=4,pin_memory=True,persistent_workers=True)
test_loader = DataLoader(test_dataset, batch_size=64, shuffle=False)
train_dataset_hash=hashlib.md5(''.join(X_train['filename'].to_list()).encode('utf-8')).hexdigest()
val_dataset_hash=hashlib.md5(''.join(X_val['filename'].to_list()).encode('utf-8')).hexdigest()
print(f'train_dataset_hash:{train_dataset_hash},val_dataset_hash:{val_dataset_hash}')
model=models.resnet50(pretrained=True)
num_ftrs = model.fc.in_features
model.fc = nn.Linear(num_ftrs, 5)
save_epoch=100
latest_model_path=f'.{os.sep}models{os.sep}model_{train_dataset_hash}_epoch{save_epoch}.pth'
while(os.path.exists(f'.{os.sep}models{os.sep}model_{train_dataset_hash}_epoch{save_epoch}.pth')):
latest_model_path=f'.{os.sep}models{os.sep}model_{train_dataset_hash}_epoch{save_epoch}.pth'
save_epoch+=100
if os.path.exists(latest_model_path):
model.load_state_dict(torch.load(latest_model_path,map_location=device))
save_epoch-=100
print(f'Loaded latest model from {latest_model_path}')
else:
save_epoch=1
model.to(device)
criterion = nn.CrossEntropyLoss(weight=class_weights)
optimizer = optim.Adam(model.parameters(), lr=1e-5, weight_decay=1e-4)
scheduler = optim.lr_scheduler.ReduceLROnPlateau(optimizer, 'min', patience=10, factor=0.5, min_lr=1e-7)
num_epochs = 2000
print(f'Training for {num_epochs} epochs')
best_val_loss=float('inf')
early_stopping_patience = 50
patience_counter = 0
for epoch in range(save_epoch,num_epochs+save_epoch+1):
model.train()
running_loss = 0.0
for inputs, labels in tqdm(train_loader, desc=f'Epoch {epoch}/{num_epochs}'):
inputs, labels = inputs.to(device), labels.to(device)
optimizer.zero_grad()
outputs = model(inputs)
loss = criterion(outputs, labels)
loss.backward()
optimizer.step()
running_loss += loss.item()
model.eval()
val_loss=0.0
correct = 0
total = 0
with torch.no_grad():
for inputs, labels in tqdm(val_loader, desc=f'Epoch {epoch}/{num_epochs}'):
inputs, labels = inputs.to(device), labels.to(device)
outputs = model(inputs)
val_loss += criterion(outputs, labels).item()
_, predicted = torch.max(outputs.data, 1)
total += labels.size(0)
correct += (predicted == labels).sum().item()
epoch_val_loss = val_loss/len(val_loader)
scheduler.step(epoch_val_loss)
print(f"Epoch {epoch}/{num_epochs}, Loss: {running_loss/len(train_loader)}, Val Loss: {epoch_val_loss}, Val Accuracy: {100*correct/total}%, lr: {optimizer.param_groups[0]['lr']}")
with open(f'.{os.sep}models{os.sep}best_model_{train_dataset_hash}_on_{val_dataset_hash}.log','a') as f:
f.write(f"epoch:{epoch},train_loss:{running_loss/len(train_loader)},val_loss:{epoch_val_loss},val_acc:{100*correct/total}%,lr:{optimizer.param_groups[0]['lr']}\n")
if (epoch) % 100 == 0:
torch.save(model.state_dict(), f'.{os.sep}models{os.sep}model_{train_dataset_hash}_epoch{epoch}.pth')
if epoch_val_loss < best_val_loss:
best_val_loss = epoch_val_loss
torch.save(model.state_dict(), f'.{os.sep}models{os.sep}best_model_{train_dataset_hash}_on_{val_dataset_hash}.pth')
with open(f'.{os.sep}models{os.sep}best_model_{train_dataset_hash}_on_{val_dataset_hash}.log','a') as f:
f.write(f'epoch:{epoch},saved best model\n')
patience_counter=0
else:
patience_counter+=1
if patience_counter >= early_stopping_patience:
print(f'Early stopping triggered at epoch {epoch}')
with open(f'.{os.sep}models{os.sep}best_model_{train_dataset_hash}_on_{val_dataset_hash}.log','a') as f:
f.write(f'epoch:{epoch},early stopping\n')
break
|
